BTN275/15 - BHD Lighting

Massey

LED Batten

Product Code:

BTN275/15

BATTEN 9W-15W LED QUAD WATTAGE TRI COLOUR OPAQUE DIFFUSER IP20 MASSEY

Category:

Battens, Commercial Lighting, Interior Lighting, Residential

Application:

commercial, residential

Product Information

Brand:

BHD Lighting.

PRODUCT TYPE:

LED Batten

Order code:

81829

Family:

Massey

body colour:

White

BODY MATERIAL:

PMMA

DIFFUSED:

Yes

DIFFUSER MATERIAL:

PMMA

DIFFUSER Type:

DIFFUSER COLOUR:

Opaque

Trim COLOUR:

Standards:

Compliance

Lumens / Meter:

Cutting Point:

Bend Diameter:

Life Span:

Driver Options:

Mounting Accessories:

Additional Notes:

Website:

Email:

Address:

ABN:

Driver

Driver Dimmable:

No

Driver Position:

Integral

Driver TYPE:

Flicker Free

CONNECTION TYPE:

Fixed Wiring

Input Current:

Inrush Current:

Output Voltage:

Output Current:

Rated Current:

Rated power:

Rated load:

Protection:

Working Humidity:

Technical Specifications

BATTERY TYPE:

BATTERY CAPACITY:

INITIAL CHARGE TIME (Hrs):

DISCHARGE TIME (Hrs):

TEST MODE:

Solar Panel Type:

Solar Panel Wattage:

Solar Charge Controller:

Detection Range:

Detection Distance:

Detection Speed:

Installation Height:

Time Delay:

Sensor Type:

Sensor Function:

Sensor Operating Temp:

Dimension & Weight

WIDTH (mm):

70

HEIGHT (mm):

70

LENGTH (mm):

600

Diameter (mm):

WEIGHT:

800g

Cutout Diameter (mm):

Spot Diameter (mm):

Base Diameter (mm):

Head Length (mm):

Mounting Type:

Accessories

Accessories:

Accessories Track:

Accessories Live Ends:

Accessories Dead Ends:

Accessories Track Joiners:

Accessories Power Adapters:

Accessories 90° Track Joiners:

Accessories "T" Track Joiners:

Accessories Track Suspension:

Accessories Thin trim 90mm Fixed:

Accessories Thin Trim Adjustable 90mm:

Accessories Wide Trim Fixed 70mm Cutout:

Accessories Wide Trim Fixed 90mm Cutout:

Accessories Curved Reflector Head 75mm Cutout:

Accessories Gimble Head 70-75mm Cutout:

Accessories Gimble Head 90mm Cutout:

Accessories Pinhole Head 75mm Cutout

Accessories Pinhole Head 90mm Cutout

Operation

INPUT VOLTAGE:

220 ~ 240Vac

INPUT FREQUENCY:

50 ~ 60Hz

ELECTRICAL RATING:

Class I

CCT:

Tri Colour 3000K, 4000K, 5700K

UGR:

Wattage:

15W ~ 9W

Max Power:

Power Consumption:

IP RATING:

IP20

IK RATING:

IK04

IC RATING:

TEMP RANGE:

-10° - +40°C

VIEWING range:

Lumens:

130l/w

CRI:

Power Factor:

>0.9

Emergency Mode:

SDCM:

<6

Beam Angle:

120°

Warranty:

5 Years
